■ Pure Sine Wave Inverter Specification
| Specification | ||||||
| Model: CT | 20112/24 | 30112/24 | 40112/24 | 50112/24 | 60112/24 | |
| Rated Power | 200 Watt | 300W Watt | 400 Watt | 500 Watt | 600 WATT | |
| Battery Voltage | DC 12/24 Volt | |||||
| Size（L*W*Hmm） | 320x220x85 | |||||
| Package Size（L*W*Hmm） | 375x293x160(1pc)/386x304x333(2pcs) | |||||
| N.W.(kg) | 3(1pc) | 3(1pc) | 3(1pc) | 3.3(1pc) | 3.5(1pc) | |
| G.W.(kg)（Carton Packing） | 3.7(1pc) | 3.7(1pc) | 3.7(1pc) | 4(1pc) | 4.2(1pc) | |
| Installation Method | Wall-Mounted | |||||
| Input | DC input voltage range | 10-15VDC （single battery voltage） | ||||
|
Voltage of the battery switched on automatically |
≥11V （single battery voltage） | |||||
| Ouput | DC Output | 12V*3+5V*1(Models of 200W-600W 24VDC does not support DC output) | ||||
| Output voltage (battery mode) | 110VAC±2%/120VAC±2%/220VAC±2%/230VAC±2%/240VAC±2% | |||||
| Output frequency (battery mode) | 50/60HZ±1% | |||||
| Efficiency | ≥85% | |||||
| Output wave form | pure sine wave | |||||
|
Solar controller |
PV charging mode | PWM | ||||
| PV charging current | 20A | |||||
|
Max PV Input Voltage(Voc) (At the lowest temperature) |
50V | |||||
| Max PV input power | 280W（12V System）/ 560W（24V System） | |||||
|
Battery Charging |
Floating charge | 13.8V(Single battery) | ||||
| Charge voltage | 14.2V(Single battery) | |||||
| Overcharge protection voltage | 15V(Single battery) | |||||
| Battery type | Valve Regulated Lead Battery | |||||
| Protection | Battery undervoltage alarm | 10.5V±0.5V(Single battery) | ||||
| Battery undervoltage protection | Inverter output: 9.5V±0.5V; DC output: 10.5V±0.2V(Single battery) | |||||
| Battery over voltage protection | 15V±0.5V(Single battery) | |||||
|
Ouput undervoltage protection (Battery mode) |
≤187VAC Turn off the output | |||||
|
Output short circuit protection (Battery mode) |
Shut down output, disconnect battery current | |||||
| Over power protection | 110% more than rated capacity | |||||
| Temperature protection | ≥90℃ machine shut off | |||||
| Display | LCD | |||||
| Thermal method | Cooling fan in intelligent control | |||||
| Communication | RS485(Optional) | |||||
| Environment | Operating temperature | -10℃~+40℃ | ||||
| Storage temperature | -15℃~60℃ | |||||
| Noise | ≤55dB | |||||
| Highest altitude | 2000m（More than derating） | |||||
| Relative humidity | 0%~95%(No condensation) | |||||
| Note: All specifications are subject to change without prior notice | ||||||
